| STANDARD/标准 |
| According to/执行标准 | MIL-STD-348A |
| Electrical Characteristics/电气特性 |
| Characteristic Lmpedance/特性阻抗 | 50Ω |
| Frequency Range/频率范围 | DC-18GHz |
| VSWR/电压驻波比 | ≤1.20Max. |
| Insertion Loss/插入损耗 | 0.3dB Max. |
| Dielecteic Withstanding Voltage/介质耐压 | 750V(rms) |
| Mechanical Characteristics/机械特性 |
| Durability /耐久性 | ≥700cycles |
| Vibration/振动 | GJB 9001C-2017(普军级） |
| Material&Planting Characteristics/材料&镀层特性 |
| Pin/中心针 | Beryllium Copper/铍青铜 | Gold Plating/镀金 |
| Body/主体 | Stainless Steel/不锈钢 | Passivation/钝化 |
| Insulator/绝缘体 | PTFE | N/A |
| Environmental Characteristics/环境特性 |
| Temperature Range/温度范围 | -65℃~+165℃ |
