| Electrical Characteristics/电气特性 | ||||
| Characteristic Lmpedance/特性阻抗 | 50Ω | |||
| Frequency Range/频率范围 | DC-18GHz | |||
| VSWR/电压驻波比 | ≤1.15Max | |||
| Insertion Loss/插入损耗 | 0.3dB Max. | |||
| Dielecteic Withstanding Voltage/介质耐压 | 750V(rms) | |||
| Mechanical Characteristics/机械特性 | ||||
| Durability /耐久性 | ||||
| Material&Planting Characteristics/材料&镀层特性 | ||||
| Pin/中心针 | Gold Plating/镀金 | |||
| Body/主体 | Passivation/钝化 | |||
| Insulator/绝缘体 | N/A | |||
| Environmental Characteristics/环境特性 | ||||
| Temperature Range/温度范围 | -45℃~+125℃ | |||
